Ideal for professional use and higher education, the VE-S5 is an excellent tool in medical industrial research. A versatile device, useful in production procedures or quality inspection of industrial products, thanks to its zoom system.
Its Greenough design allows three-dimensional observation of insects. The VE-S5 is ideal in the dissection and classification of organisms in entomology and taxonomy, as well as the observation and selection of viable embryos in livestock.
TECHNICAL DATA
| Eyepieces: WF 10X/20 mm |
| Objectives: Variable magnification Zoom System 0.7X, 0.8X, 1X, 1.5X, 2X, 3X, 4X and 4.5X (from 7 to 45 total increases) |
| Stage: Interchangeable 60 mm/2.3" diameter stage, opaque glass and double-sided white / black |
| Focus: Coarse anti-slip control knob |
| Illumination: Transmitted and incident LED |
| Power supply: 110/240V, 50/60 Hz AC adapter. |
| Dimensions: 225 x 340 x 270 mm / 8.8" x 13.3" x 10.6" |
Main Features
- Trinocular head, inclined at 45 °.
- Stage with clamps.
- Phototube with 23 mm diameter, compatible with VELAB MC, LX series cameras and VE-SCOPEPAD tablet.
- Two interchangeable plates: opaque glass, for transmitted light and double-sided white / black, for incident light.
- Interpupillary distance of 55 ~ 75mm.
- Stable, robust, reinforced and easy to transport.
- Lighting with independent switches.
- Diopter adjustment in both eyepieces.
- Anti-slip ring on lens and cap.
Applications
- Education
- Industrial
- Research
ACCESSORIES INCLUDED
- Dust cover.
- Power cord.
WARRANTY
10-years limited warranty.
